Circles – Architecture & Identity Deep Dive

1. System Overview

Circles is built as a fully serverless web application on AWS. The design emphasizes a small, well-defined attack surface, straightforward scaling, and a modern cloud identity model.

• UI & Static Assets: S3 (private) + CloudFront
• API Surface: API Gateway (REST) with a /prod stage
• Business Logic: AWS Lambda (Node.js 20)
• Data: DynamoDB tables for messages, circles, memberships
• Identity & Auth: Amazon Cognito User Pool + Hosted UI + JWT
• Routing & Domain: CloudFront + Route 53 + ACM TLS

2. Request Flow: Browser → CloudFront → API → DynamoDB

The basic message flow looks like this:

1. The user navigates to https://circles.behrens-hub.com. CloudFront serves the SPA (HTML/JS/CSS) from a private S3 bucket via an Origin Access Identity.
2. When the SPA loads, it:
   • Parses any tokens from the URL fragment (if returning from Cognito)
   • Shows signed-in state and the current user
   • Calls GET /api/circles/config to discover which circles the user belongs to
   • Loads messages for the selected circle via GET /api/circles?familyId=…
3. All API requests go through CloudFront, which routes /api/* to API Gateway. API Gateway is configured with:
   • A Cognito User Pool authorizer
   • A /prod stage
   • Methods that proxy to a single Lambda function
4. When the user posts a message:
   • The SPA sends POST /api/circles with JSON body and an Authorization: Bearer <id_token> header.
   • API Gateway validates the JWT using the Cognito authorizer.
   • If valid, claims are injected into event.requestContext.authorizer.claims for the Lambda to consume.
5. Lambda:
   • Extracts the user’s sub (userId) and other claims (e.g., email, name)
   • Checks the CircleMemberships table to ensure the user is allowed to read or write in the requested circle
   • Reads or writes data in CirclesMessages as appropriate
   • Returns a JSON response back through API Gateway → CloudFront → browser

3. Data Model: Messages, Circles, Memberships

DynamoDB is used for its simplicity, scalability, and pay-per-request pricing. The data model is minimal but intentional.

3.1 CirclesMessages

Stores all messages for all circles.

• Table: CirclesMessages
• Partition key: familyId (string) – effectively the circle ID
• Sort key: createdAt (string, ISO timestamp)

Example item:

{
  "familyId": "behrens",
  "createdAt": "2025-12-04T18:22:11.123Z",
  "author": "Scott",
  "text": "Hello from the real Circles API!"
}

3.2 Circles

Stores metadata for each circle.

• Table: Circles
• Partition key: circleId (string)

Example item:

{
  "circleId": "behrens",
  "name": "Behrens Family",
  "description": "Primary family circle"
}

3.3 CircleMemberships

Defines who belongs to which circles, and with what role.

• Table: CircleMemberships
• Partition key: userId (Cognito sub)
• Sort key: circleId (string)
• Additional fields: role, joinedAt

This layout makes it very easy to:

• List all circles a user belongs to (one query on userId)
• Check whether a user can access a specific circle (look up { userId, circleId })
• Extend into role-based behavior (owner, member, etc.) later

4. Identity & Authorization

Because I’ve spent much of my career working with enterprise identity, RBAC, and SSO, I wanted Circles to use a modern identity pattern rather than a toy implementation. The stack centers on Amazon Cognito and JWTs.

4.1 Cognito Setup

• Cognito User Pool for managing users
• User Pool Client configured for a browser-based SPA (no client secret)
• Hosted UI for sign-in and sign-up
• Implicit flow using response_type=token for this demo
• Redirect URI: https://circles.behrens-hub.com/

In production, I would shift this to Authorization Code + PKCE for stronger security and refresh token support, but the current setup keeps the demo code simple while still demonstrating the core identity patterns.

4.2 Token Flow

1. The user clicks "Sign in" in the SPA. The browser redirects to the Cognito Hosted UI /oauth2/authorize endpoint with:
   • client_id
   • response_type=token
   • scope=openid email profile
   • redirect_uri=https://circles.behrens-hub.com/
2. After sign-in, Cognito redirects back to the SPA with an id_token (and access_token) in the URL fragment.
3. The SPA parses the fragment via window.location.hash, extracts the tokens, and stores them in localStorage along with decoded claims.
4. All API calls include:

   Authorization: Bearer <id_token>

5. API Gateway’s Cognito authorizer validates the token and injects claims into event.requestContext.authorizer.claims for Lambda.

4.3 Backend Authorization (Zero Trust)

A key design choice was to enforce circle membership on the backend. The SPA is not trusted to decide what circles a user may see.

At a high level, each request is handled as follows:

• Lambda reads userId = claims.sub and authorName = claims.name || claims.email
• For GET /api/circles, if a familyId is specified:
  • Lambda checks CircleMemberships for { userId, circleId: familyId }
  • If no record is found, it returns 403 Forbidden
• For POST /api/circles:
  • Same membership check is performed
  • If allowed, Lambda writes the message using authorName from the JWT, not from the client body

This pattern mirrors how I’d handle authorization in a larger system: frontend drives the experience, but the backend is the source of truth for “who can access what.”

5. Secure SDLC Maturity

From a secure SDLC perspective, Circles follows a staged maturity model. Security is not an afterthought, but it is also not overbuilt for a small demo.

• Stage 0 – Infrastructure defaults: private buckets, HTTPS-only access, IAM least privilege, CloudFront as the only public edge.
• Stage 1 – Authentication: Cognito User Pool + Hosted UI with JWT-based sign-in; API Gateway authorizer ensures only authenticated users reach the Lambdas.
• Stage 2 – Authorization: DynamoDB-backed circle membership, enforced in Lambda using userId from JWT claims.
• Stage 3 – Future enhancements: planned evolution to Authorization Code + PKCE, richer roles, audit logging, and monitoring as needed.

The goal isn’t to turn a small demo into a security product; it’s to show that I understand how to layer appropriate controls over time while keeping cost and complexity aligned with the product’s stage.

6. Cost & Simplicity

Cost sensitivity was an explicit design constraint. The architecture avoids NAT gateways, long-running compute, and unnecessary managed services. Instead, it leans on:

• Pay-per-request DynamoDB tables
• Serverless Lambda functions
• CloudFront caching and edge delivery
• Cognito’s fully managed identity service

The intent was to build the simplest secure system that could deliver the MVP, while leaving space to evolve if usage grows. The re-architecture cost of scaling up later is lower than the cost of overbuilding up front.

7. Summary

This deep dive reflects how I think about architecture and identity when I’m wearing both the product and technical hats. Even in a small app, the principles are the same as in larger initiatives: clear boundaries, identity-first design, minimal trusted surfaces, and a bias toward simple, evolvable systems.

For teams, it means I can converse comfortably with engineers, architects, and security specialists – and still keep the conversation grounded in user value and business outcomes.
